Product Details:
Payment & Shipping Terms:
|
| Conductor: | 99.99% Pure Copper/CCA/CCAG | Length: | 1m 2m 3m 5m Or Customized |
|---|---|---|---|
| Wire Guage: | 24/26/28/30AWG | Jacket: | PVC/LSNH |
| Storage Temperature: | -20℃ ~ 60℃ | .Operating Temperature: | 0℃ ~ 50℃ |
| High Light: | Solid Copper RJ45 Patch Cord,UTP RJ45 Patch Cord,3m CAT5E Ethernet Cable |
||
CAT5E round patch cable as the carrier of monitoring, voice, data, media, is used in the connection of the socket of office and facility terminal, or the connection of the modular socket in central office and equipment, which is satisfied the requirements of the application of Class E line.
Product:
| Material | oxygen free copper + PVC Inner Layer + 50µ gold-plated precious metals |
| Rate | 100MBPS |
| Bandwidth | 100MHZ |
| Structure | 24AWG |
| Pluggable | ＞750 times |
| Application | Automotive,Electrical,Industry,Home applications |
| Service | OEM and ODM products are acceptable |
| Samples | Samples confirmed first before mass production |
| Color | Blue Yellow Black or customized |
| Length | 0.5/1/2/3/5m or customized |
Charactrestics:
1.Characteristic Impedance (1-130MHz): 100 Ω±15 ohm;
2.Average characteristic impedance(1-130MHz): 100 Ω±10 ohm;
3. Minimum mutual capacitance: 47 pF/M;
4. The maximal balancing capacity: 300 pF/M;
5. Direct current resistance: 170 ohm/km;
6. The maximal balance resistance: 2%;
7. Nominal velocity of propagation (MVP): 0.69c.
